Velowave Pony Compact
Step-Through All-Terrain Electric Bike - Top Speed 25mph - 750W
Pony Compact
Enjoy effortless and confident rides with Pony, an E-Bike crafted for every adventure. Its step-through frame design ensures easy mounting and dismounting, while its sturdy wide tires offer traction on diverse terrains, from sandy beaches to snowy mountains. Discover exhilarating rides like never before with Pony!
TOP SPEED
MOTOR POWER
Removable Battery
TIRES
Rider Height
PAYLOAD CAPACITY
All Terrains Kenda Fat Tire
Kenda 20"*4.0" Fat Tire, anti-skidding, wear-resistant, and adapt to snow, sand, and various terrains. The fat tire enables smooth riding on rugged terrains means you can get more cycling experiences.
750W BAFANG Geared Hub Motor
750W high-speed BAFANG geared motor, strong and powerful, providing strong electric power, and making it stable to reach speed peaks. You can cruise in the wild with little to no effort.
Comfortable Wide Saddle
We focus on details, and for a more comfortable riding experience, we choose a widened and enlarged comfortable seat pad.
6061 Aluminum Durable Structural
This fat tire e-bike has an aluminum body for strength. The appearance design is simple and technological.
Removable 48V 15Ah LG Battery
Equipped with a 48V/15AH lithium battery and LG battery, it can travel 25-40 miles per full charge. Support fast charging, charge about 80% in 4 hours, and fully charge in 8 hours.
Front Hydraulic Suspension Fork
Frame vibration is reduced when riding on rough roads. It makes the ride more stable, more comfortable, and more controllable. It avoids excessive vibrations that could cause hands to leave the handlebars for increased safety.
Shimano 7-Speed Drivetrain
The Shimano 7-speed drivetrain offers smooth shifting to help you adjust your riding speed for different sections and conditions.
Multifunctional Color Display
The front and rear hydraulic disc brake system is very smooth and can exert a good braking effect in any condition. And provides assist level, battery indicator, riding speed, and mileage data.
High-luminance Headlight
The bright 48V 10W LED Light provides a safer and more enjoyable environment for night riding. Easy riding day and night.
SPECIFICATIONS
Specifications
| Frame Size | Standard (mm) |
| Handlebar Height | 1130mm |
| Reach | 440mm |
| Head Tube Length | 173mm |
| Seat Tube Length | 349mm |
| Standover Height | 670mm |
| Wheelbase | 1131mm |
| Total Length | 1715mm |
| Seat Height Min/Max | 775/990mm |
General
- Classes:Class 3(Ebikes can go up to 28mph with pedal assistance)
- Max Speed: 25MPH by pedal, 20MPH by throttle
- Range: 25 to 40 Mile by Pedal; 23 Mile by Throttle(Calculation based on rider's weight of 75kg. Range varies according to road condition, weather, rider's weight etc.)
Frameset
- Frame:6061 Aluminium, Removable Battery, Internal Routing
- Fork: Hydralic Suspension Fork
- Fenders:Included
Wheels
- Rim Material: Aluminum
- Rim Size: 20 x 3.0
- Rim Type: Wheel with Integral Hub
- Tire: Kenda Fat Tires
- Tire Size: 20" x 4.0"
E-system
- Battery: 48V 15Ah, 720Wh, LG 21700 Cells
- Charger: Input 100-240V~, 2.8A(Max.), 50-60Hz. Output 54.6V⎓2.0A, Aviation Connector. UL LISTED
- Motor:BAFANG Geared Hub Motor, Rated 750W, Peak 1000W, Max Torque 80NM
- Controller: 48V 25A Peak
- Display: Multifunctional Color-Screen Display
- Pedal Assist: Cadence Sensor
- Throttle: Thumb Throttle
- Front Light: 48V 10W LED Light
Drivetrain
- Shifter: Shimano, 7-Speed
- Rear Derailleur: Shimano, Long Cage
- Crank & Chainring:52T, 170mm Alloy Crank
- Freewheel: 7-Speed
- Pedal: Alloy Platform Pedals
Components
- Saddle: Comfortable Wide Saddle
- Handlebar:Alloy, 750mm width
- Grips: Nylon Lock-on
- Brake: Front & Rear Hydralic Disc Brakes
- Brake rotor: 180mm, 1.9mm thick
- Kickstand: Side Kickstand
- Seatpost: Forged Alloy, Ø30.4*350mm
- Stem:Bar bore: ∅31.8mm, Clamp I.D.: ∅28.6mm, HEIGHT: 40mm, RISE: 0°
- Handlebar:Aluminum Ø31.8mm, Width 710mm
Weight
- Net Weight:36kg(79.4lb)
- Gross Weight:45.6kg(100.5lb)
- Battery Weight:4.2kg(9.3lb)
- Weight limit:150kg(330lb) Payload Capacity
Size
- Product Size:1720x1130x750mm
- Packing Size:1450x320x800mm
